NEX10 female to 7/16 DIN female Low PIM Adapter DC-6GHz -160dBc 5G Infrastructure

Our NEX10 Female to 7/16 DIN Female Adapter is engineered as a critical Low PIM bridge for modern 5G FR1 infrastructure. Designed for seamless interoperability up to DC-6GHz, this adapter connects compact NEX10 female ports on O-RAN radio units or Small Cells to robust 7/16 DIN female antenna feeder cables, ensuring PIM excellence (typically ≤ -160 dBc). Built with durable materials and often featuring IP67/IP68 weatherproofing, it provides reliable, high-performance connectivity in the most demanding outdoor environments, preventing PIM bottlenecks and preserving signal integrity across your telecommunication network

Material & Finishing

• Center conductor : beryllium-copper,Gold Plating
• Insulators : PTFE
• Body: Brass,Ternary alloy Plating
• Other: Brass,Ternary alloy Plating
• Gasket: Silicone Rubber
• Connector Type: NEX10 female to 7/16 DIN female

Electrical Data

• Frequency Range: DC -6GHz
• PIM Rating: ≤ -160 dBc
• Impedance: 50 Ohm
• VSWR: 1.15(DC-3GHz)
